9.5 Entering the machine data
Commissioning
9-90
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
9.5 Entering the machine data
Overview
The most important machine data of the individual subareas are listed here to assist you.
For a detailed description of the machine data and interface signals, please refer to the
Descriptions of Functions (cf. cross-references in the tables of Chapter 7 “Machine Data and
Setting Data”).
Note
The default values of the machine data have been chosen such that usually no change is
required.
Entering the machine data (MD)
Before you can enter the machine data, the password for protection level 2 must be set.
Use the relevant softkey to select the following machine data areas and to change the ma-
chine data if necessary:
S General machine data MD 10000 ... 19999
S Channel machine data MD 20000 ... 29999
S Axis machine data MD 30000 ... 39999
S Display machine data MD 1 ... 999
S Drive machine data r0001 ... r9999 (read-only)
p0001 ... p9999 (read and write-enabled)
The data you have entered are written to the data memory immediately. An exception is the
drive machine data. To save the drive machine data permanently, set the parameter p971 for
each individual drive object separately or set p977 of the CU (SINAMICS_I) to “1” and wait
until it is reset automatically. If you forget to save the data, the old data is effective again
after the next drive reset.
The machine data is activated depending on the machine data property “Activated”,
Section 9.1.2.
