A.2 Setting data
Machine and Setting Data 802D
A-226
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
A.2 Setting data
MD
number
SD identifier as of version
Unit Brief description Activation
Display filter Attributes Data type
Default Dimension Default value Minimum value Maximum value Protection
System * Dimension Default value Minimum value Maximum value Protection
* Values other than those in the standard system
Note regarding the value definition:
TRUE corresponds to 1
FALSE corresponds to 0
41010 JOG_VAR_INCR_SIZE
– JOG mode: Size of variable increment IMMED.
– – DOUBLE
Default – 0. – – 7/7
41110 JOG_SET_VELO
mm/min Axis velocity in the JOG mode IMMED.
– – DOUBLE
Default – 0.0 – – 7/7
41130 JOG_ROT_AX_SET_VELO
rev/min Axis velocity of the rotary axes in the JOG mode IMMED.
– – DOUBLE
Default – 0.0 – – 7/7
41200 JOG_SPIND_SET_VELO
rev/min Speed for spindle jog mode IMMED.
– – DOUBLE
Default – 0.0 – – 7/7
42000 THREAD_START_ANGLE
degrees Thread start angle [deg] IMMED.
– – DOUBLE
Default – 0 – – 3/3
42010 THREAD_RAMP_DISP
mm Acceleration pattern of the axis when thread cutting IMMED.
– – DOUBLE
Default 2 –1.0, –1.0 –1.0 999999. 3/3
42100 DRY_RUN_FEED
mm/min At least the programmed velocity with active dry run IMMED.
– – DOUBLE
Default – 5000 – – 7/7
42101 DRY_RUN_FEED_MODE
– Mode for dry run velocity IMMED.
– – BYTE
Default – 0 0 12 7/7
42110 DEFAULT_FEED
mm/min Default value for path feedrate IMMED.
– – DOUBLE
Default – 0 – – 7/7
42120 APPROACH_FEED
mm/min Path feed in approach blocks IMMED.
– – DOUBLE
Default – 0 – – 2/2
