Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.2 Setting data
A-227
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
42125 SERUPRO_SYNC_MASK
– Synchronization in approach blocks IMMED.
– – DWORD
Default – 0 – – 2/2
42140 DEFAULT_SCALE_FACTOR_P
– Default scaling factor for address P IMMED.
– – DWORD
Default – 1 – – 7/7
42150 DEFAULT_ROT_FACTOR_R
– Default rotation factor for address R IMMED.
– – DOUBLE
Default – 0. – – 7/7
42160 EXTERN_FIXED_FEEDRATE_F1_F9
– Fixed feedrates F1 – F9 IMMED.
– – DOUBLE
Default 10 0.0, 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0, 0.0, 0.0
– – 7/7
42162 EXTERN_DOUBLE_TURRET_DIST
– Tool distance of dual resolver head IMMED.
– – DOUBLE
Default – 0. – – 7/7
42200 SINGLEBLOCK2_STOPRE
– Activate debug mode for SBL2 IMMED.
– – BOOLEAN
Default – FALSE – – 7/7
42440 FRAME_OFFSET_INCR_PROG
– Work offset in frames IMMED.
– – BOOLEAN
Default – TRUE – – 7/7
42442 TOOL_OFFSET_INCR_PROG
– Tool length compensations IMMED.
– – BOOLEAN
Default – TRUE – – 7/7
42444 TARGET_BLOCK_INCR_PROG
– Incremental programming with block search IMMED.
– – BOOLEAN
Default – TRUE – – 7/7
42480 STOP_CUTCOM_STOPRE
– Alarm response with TRC and preprocessing stop IMMED.
– – BOOLEAN
Default – TRUE – – 3/3
42490 CUTCOM_G40_STOPRE
– Retraction behavior of TRC with preprocessing stop IMMED.
– – BOOLEAN
Default – FALSE – – 3/3
42494 CUTCOM_ACT_DEACT_CTRL
– Approach/retraction behavior with 2–1/2D TRC IMMED.
– – DWORD
Default – 2222 – – 3/3
42496 CUTCOM_CLSD_CONT
– Behavior of the TRC with closed contour IMMED.
– – BOOLEAN
Default – FALSE – – 3/3
