Siemens SINUMERIK 802D sl Instruction Manual

A.1 List of machine data
Machine and Setting Data 802D
A-202
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
10713 M_NO_FCT_STOPRE
– M function with preprocessing stop POWER ON
EXP, N12, N07 – DWORD
Default 15 –1, –1, –1, –1, –1, –1, –1,
–1, –1, –1, –1, –1, –1, –1,
–1
– – 2/2
10714 M_NO_FCT_EOP
– M function active for spindle after reset POWER ON
EXP, N07 – DWORD
Default – –1 – – 2/2
10715 M_NO_FCT_CYCLE
– M function to be replaced by a subroutine POWER ON
EXP, N12, N07 – DWORD
Default 10 –1, –1, –1, –1, –1, –1, –1,
–1, –1, –1
– – 2/2
10716 M_NO_FCT_CYCLE_NAME
– Subroutine name for replacement of an M function POWER ON
EXP, N12, N07 – STRING
Default 10 – – 2/2
10717 T_NO_FCT_CYCLE_NAME
– Subroutine name for replacement of a T function POWER ON
EXP, N12, N07 – STRING
Default –1 – – 2/2
10718 M_NO_FCT_CYCLE_PAR
– M function replacement by parameters POWER ON
EXP, N12, N07 – DWORD
Default – –1 – – 2/2
10719 T_NO_FCT_CYCLE_MODE
– Parameterization of the T function replacement POWER ON
EXP, N12, N07 – DWORD
Default – 0 0 1 2/2
10735 JOG_MODE_MASK
– Enable jogging in the AUTOMATIC mode POWER ON
EXP, N01 – DWORD
Default – 0 0 0x1 2/2
10760 G53_TOOLCORR
– Effect with G53, G153 and SUPA POWER ON
N12 – BOOLEAN
Default – FALSE – – 2/2
10810 EXTERN_MEAS_G31_P_SIGNAL
– Assignment of the measuring inputs for G31 P.. POWER ON
EXP, N12 – BYTE
Default 4 1, 1, 1, 1 0 3 2/2
10812 EXTERN_DOUBLE_TURRET_ON
– Double–resolver head with G68 POWER ON
EXP, N12 – BOOLEAN
Default – FALSE – – 2/2
10820 EXTERN_INTERRUPT_NUM_RETRAC
– Interrupt number f. rapid retraction (G10.6) POWER ON
EXP, N12 – BYTE
Default – 2 1 8 2/2
