Siemens SINUMERIK 802D sl Instruction Manual

9.11 Diagnosis via STARTER
Commissioning
9-118
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Features
S Measuring functions
– Current controller setpoint step change (downstream of the current setpoint filter)
– Speed controller reference frequency response (downstream of the current setpoint
filter)
– Speed controller setpoint step change (downstream of the speed setpoint filter)
– Speed controller disturbance variable step change (fault downstream of the current
setpoint filter)
– Speed controller reference frequency response (downstream of the speed setpoint
filter)
– Speed controller reference frequency response (upstream of the speed setpoint filter)
– Speed controller interference frequency response (fault downstream of the current
setpoint filter)
– Speed-controlled system (excitation downstream of the current setpoint filter)
Starting / stopping the measuring function
!
Caution
With the corresponding measuring function parameter settings (e.g. offset), the motor can
“drift” and travel to its end stop.
The motion of the drive is not monitored with the measuring function activated.
To start the function generator, proceed as follows:
1. Provide for the prerequisites for starting the measuring function.
– Activate the control panel.
Drives –> Drive_x –> Commissioning –> Control board
– Turn on the drive.
Control board –> Issue enable signals –> Switch on
2. Select the drive (as the control panel).
3. Set the measuring function,
e.g. current controller setpoint step change.
4. Load the settings to the target system (“Download parameters” pushbutton)
5. Start the measuring function (“Start Measuring Function” pushbutton)
To stop the function generator, proceed as follows:
“Stop Measuring Function” pushbutton
