Siemens SINUMERIK 802D sl Instruction Manual

Starting Up the PLC
11.3 PLC alarms
11-169
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
S %O integer octal number
S %X integer hexadecimal number
S %B binary representation of a 32-bit value
S %F 4-byte floating point number
Examples of user alarm texts (Note: The text after the ”//” is a comment and is not dis-
played.)
S 700000 ‘’ ‘’ // only the user alarm number
S 700001 ‘’ Hardware limit switch + of the X axis’’
S 700002 ‘’ %D ‘’ // only a variable as an integer decimal number
S 700003 ‘’ Alarm number with a fixed alarm text and the variable %X ‘’
S 700004 ‘’ %U Alarm number with variable and fixed alarm text ‘’
S 700005 ‘’Axis monitoring active : %U’’
Display: 700005 Axis monitoring active : 1
or 700005 Axis monitoring active : 3
