Machine and Setting Data 802D
Data type
BOOLEAN Boolean value: 1 (TRUE) or 0 (FALSE)
BYTE 8-bit value,
as an integer value: –128 ... 127,
as a hexadecimal value: 00 ... FF
as a character as per ASCII character set, e.g. “a”
STRING Sequence of characters (max. 16)
WORD 16-bit value,
as an INTEGER value: –32768 ... 32767,
as a hexadecimal value: 0000 ... FFFF
UNSIGNED WORD 16-bit value,
as an integer value: 0 ... 65535,
as a hexadecimal value: 0000 ... FFFF
INTEGER 16-bit value (here defined locally),
integer value: –32768 ... 32767
DWORD 32-bit value,
as an integer value: –2147483648 ... 2147483647,
as a hexadecimal value: 0000 0000 ... FFFF FFFF
UNSIGNED DWORD 32-bit value,
as an integer value: 0 ... 4294967295,
as a hexadecimal value: 0000 0000 ... FFFF FFFF
DOUBLE 64-bit value,
floating point value: " 4.19  10
–307
bis " 1.67  10
308
Range of values (minimum/maximum value)
If no range of values is specified, the data type determines the input limits and the field is
marked with “***”.
