Siemens SINUMERIK 802D sl Instruction Manual

Standards and Approvals
B.3 Mechanical and climatic ambient conditions for operation
B-235
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Climatic ambient conditions
The control system can be used under the following climatic ambient conditions:
Ambient conditions Fields of application Remarks
Temperature From 0 to 50 _C With a simultaneity of 50 %
Relative humidity 5 to 95%, Without condensation, corres-
ponds to relative humidity (RH)
severity level 2 in accordance
with IEC 1131-2
Air pressure 1,080 ... 795 hPa –
Pollutant concentration
SO
2
: < 0.5 ppm;
Relative humidity < 60%, without
condensation
H
2
S: < 0.1 ppm;
Relative humidity < 60%, without
condensation
Tested:
10 ppm; 4 days
1 ppm; 4 days
Mechanical ambient conditions
The mechanical ambient conditions for the control system are specified in the table below in
the form of sinusoidal waves.
Mechanical ambient conditions Operation Transport (in packaging)
Vibration tested in accordance
with DIN EN 60068-2-68
10 to 58 Hz: 0.35 mm
58 to 200 Hz: 50 m/s
2
5...9 Hz: 3.5 mm
9 to 200 Hz: 10 m/s
2
Shock resistance tested in accor-
dance with DIN EN 60068-2-27
10 g peak value, 6 ms duration
100 shocks in each of the 3
axes vertical to one another
10 g peak value,
6 ms duration
100 shocks in each of the
3 axes vertical to one another
Vibration reduction
If the control system is subjected to major impacts or vibration, appropriate measures must
be taken to reduce the acceleration or the amplitude of the vibration.
We recommend mounting the control system on shock-absorbing material (e.g. vibration-
absorbing metal).
