System
8.5 SYSTEM - "PLC" softkeys
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
145
3URJUDP
OLVW
&RS\
3DVWH
'HOHWH
Using the PLC, you may select part programs and run them via the PLC. To this end, the
PLC user program writes a program number to the PLC interface, which is then converted to
a program name using a reference list. It is possible to manage max. 255 programs.
Figure 8-41 PLC program list
This dialog displays all files of the MPF directory and their assignment in the reference list
(PLCPROG.LST) in the form of a list. You can use the TAB key to switch between the two
columns. The Copy, Insert and Delete softkey functions are displayed with reference to a
specific context. If the cursor is placed on the left-hand side, only the Copy function is
available. On the right-hand side, the Insert and Delete functions are provided to modify the
reference list.
List of references for interface signals
SINUMERIK 802D sl Function Manual; Various Interface Signals (A2)
SINUMERIK 802D sl List Manual
Writes the selected file name to the clipboard.
Pastes the file name at the current cursor position.
Deletes the selected file name from the assignment list.
