10.1 Fundamental principles of NC programming
Surface grinding
200 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
Address Meaning Value assignments Information Programming
G41 Tool radius compensation left of contour
G42 Tool radius compensation right of contour
G500 Settable work offset OFF
G54 1st Settable zero offset
G55 2nd Settable zero offset
G56 3rd Settable zero offset
G57 4th Settable zero offset
8: Settable zero offset
modally effective
G58 5th Settable zero offset
G59 6th Settable zero offset
G53 Non-modal skipping of the settable work
offset
9: Skipping of the settable work
offset
non-modal
G153 Non-modal skipping of the settable work
offset including base frame
G60 * Exact stop
G64 Continuous-path mode
10: Approach behavior
modally effective
G9 Non-modal exact stop 11: Non-modal exact stop
non-modal
G601 * Exact stop window, fine, with G60, G9
G602 Exact stop window, coarse, with G60, G9
12: Exact stop window
modally effective
G70 Inch dimension input
G71 * Metric dimension data input
13: Inch / metr.dimension input
modally effective
G700 Inch dimension data input; also for
feedrate F
G710 Metric dimension data input; also for
feedrate F
G90 * Absolute dimension data input
G91 Incremental dimension
14: Absolute / incremental
dimension
modally effective
G94 * Feed F in mm/min
G95 Feedrate F in mm/spindle revolutions
G96 Constant cutting rate ON
(F in mm/rev., S in m/min)
G96 S... LIMS=... F...
G97 Constant cutting speed OFF
15: Feedrate / spindle
modally effective
G450 * Transition circle
G451 Point of intersection
18: Behavior at corners when
working with tool radius
compensation
modally effective
BRISK * Jerking path acceleration
SOFT Jerk-limited path acceleration
21: Acceleration profile
modally effective
FFWOF * Feedforward control OFF
FFWON Feedforward control ON
24: Precontrol
modally effective
WALIMON * Working area limitation ON 28: Working area limitation
modally effective
; applies to all axes activated
via setting data;
values set via G25, G26
