Appendix
A.2 Parameter tables of the tool data
Surface grinding
346 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
In addition to the default coding of the tool data (tool type, cutting edge position, etc.), the
following coded parameters are used.
Encoding Wheel type $TC_TPC1[T]
0 free contour
1 Standard contour straight without rear definitions
2 Standard contour straight with rear definitions
3 Standard contour inclined left
4 Standard contour inclined right
5 Standard contour straight profile roller with geo axes
Encoding Dressing mode at the diameter $TC_DP19[T,1]
0 neither drawing nor plunging (3rd dresser)
1 drawing (last active dresser)
2 plunging (last active dresser)
11 drawing (1st dresser)
12 plunging (1st dresser)
21 drawing (2nd dresser)
22 plunging (2nd dresser)
Encoding Dresser type $TC_DPC6[T,_GC_DNUM+dresser-1]
0 Dresser geometry axes (diamond) non-rotating
1 Dresser geometry axes (diamond) non-rotating
...
11 Dresser, geometry axes (form roll) rotating
12 Dresser, geometry axes (form roll) rotating
21 Dresser, geometry axes (diamond) rotating
