Appendix
A.3 Miscellaneous
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
353
The selection is displayed in the Zhuyin input field and should be confirmed using the
<Input> key or by entering an additional digit.
Figure A-8 Zhuyin input method
If the field for the sound is "green" and if "black triangles" are displayed to the left, then using
the cursor keys <down> <up> additional syllables can be selected.
Afterwards, the desired syllable should be selected using the cursor keys <left> or <right>
and the selection confirmed using the <Input> key.
Figure A-9 Zhuyin input method, selected syllable in the program editor
Pinyin input method
Using the tabulator, you selected the Pinyin input field.
Characters can be selected according to the phonetic language, whose sound can be
formed by compiling letters from the Roman alphabet.
The editor will then show a list of characters that correspond to that particular sound.
Figure A-10 Pinyin input method
If the field for the sound is "green" and if "black triangles" are displayed to the left, then using
the cursor keys <down> <up> additional characters can be selected.
