Setup
4.2 Create new tool
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
37
7RRO
GDWD
1RPLQDO
GLPPRQLW
*HRPHWU\
GDWD
In the next step, the tool data are to be entered.
● Nominal dimensions for monitoring
● Geometry data
● Technological data
● Data for the dressers
Nominal dimensions and monitoring
This function opens in input screen into which grinding wheel nominal dimensions and
monitoring data are entered.
Figure 4-6 Grinding wheel nominal dimensions and monitoring data
Geometry data
This function is used the enter the wheel geometry for the wheel type selected.
Figure 4-7 Geometry example data for a vertical wheel with back-slope
