Setup
4.2 Create new tool
Surface grinding
38 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
7HFKQR
ORJ\GDWD
The following wheel types are available:
● Vertical wheel without back-slopes (type 1)
● Vertical wheel with back-slopes (type 2)
● Left-hand side inclined wheel (type 3)
● Right-hand side inclined wheel (type 4)
● Free contour (type 0)
The input screen is self-explaining.
Note
A red dot shown in the diagrammatic sketch indicates the geometry value just being entered.
Technological data
By means of the technological data, the wheel type dependent dressing technology is
defined.
Figure 4-8 Technology example data for a vertical wheel with back-slope
