Setup
4.2 Create new tool
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
39
VW
GUHVVHU
Dresser
Use the "1st dresser", "2nd dresser" or "3rd dresser" softkeys to access the dialog box for
entering or verifying the dresser data.
Figure 4-9 Fixed dresser
Use the "Type" toggle field to select the dresser type:
Fixed dresser: Tile/Diamond
Form roll 1 to 3
Diamond roll 1 to 3
Enter the parameters depending on the selection made.
Figure 4-10 Form roll
