Setup
4.6 Manual grinding
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
47
2VFLOODWLRQ
GDWD
Manual grinding, oscillation
The figure below shows an input screen with parameters for manual grinding with oscillation:
Figure 4-20 Manual grinding with oscillation
If you have selected oscillation, then you should use this function to enter the oscillation data
(see figure below):
Figure 4-21 Manual grinding with oscillation data in X and Z
