Automatic mode
6.9 Execute from external
Surface grinding
82 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
&XVWRPHU
&)FDUG
86%
GULYH
([W
H[HFXWLRQ
Start in the following start screen of the Program Manager:
Figure 6-13 The "Program Manager" start screen
Use vertical softkey "Ext. execution" to transmit the selected external program to the control
system; to execute this program, press <NC START>.
While the contents of the buffer memory are being processed, the blocks are reloaded
automatically.
Operating sequence, execution from customer CompactFlash Card or USB FlashDrive
Requirement: The control system is in the "Reset" state.
Select the <AUTOMATIC> mode key.
Press the <PROGRAM MANAGER> key on the machine control panel.
Press the "Customer CF card" or "USB drive".
You can then access the directories of the "Customer CF Card / USB FlashDrive".
Place the cursor bar on the desired program.
Press "Ext. execution".
The program is transferred into the buffer memory and selected and displayed in the
program selection automatically.
Press the <NC START> key.
Machining starts. The program is reloaded continuously.
