Automatic mode
6.9 Execute from external
Surface grinding
Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
83
At the end of the program or in case of <RESET>, the program is automatically removed
from the control system.
Note
For "Execute externally", no block search is possible.
Requirements for external execution via network
● The control system and the external PC are connected via Ethernet.
● The RCS tool is installed on the PC.
The following conditions are required on the the devices:
1. Control: (see "User Management")
– Create an authorization for using the network using the following dialog:
Operating area <SYSTEM> > "Service Display" > "Service Control" > "Service
Network" > "Authorization" > "Create"
2. Control: (see "User log in - RCS log in")
– Log in for the RCS connection using the following dialog:
Operating area <SYSTEM> > vertical softkey "RCS log in" > "Log in"
3. PC:
– Start the RCS tool.
4. PC:
– Activate the drive/directory for network operation.
5. PC:
– Establish an Ethernet connection to the control.
6. Control: (see "Connecting / disconnecting a network drive")
– Connect to the directory released for sharing on the PC using the following dialog:
Operating area <SYSTEM> > "Service Display" > "Service Control" > "Service
Network" > > "Connect" > "RCS Network" (select a free drive of the control > Enter the
server name and the directory released for sharing on the PC, for example:
"\\123.456.789.0\External Program")
