Automatic mode
6.9 Execute from external
Surface grinding
84 Programming and Operating Manual, 11/2012, 6FC5398-5CP10-3BA0
5&6
FRQQHFW
([W
H[HFXWLRQ
Operating sequences for external execution via network
Select the <AUTOMATIC> mode key.
Press the <PROGRAM MANAGER> key on the machine control panel.
Press "RCS connect.".
You go to the directories of the PC.
Place the cursor bar on the desired program.
Press "Ext. execution".
The program is transferred into the buffer memory and selected and displayed in the
program selection automatically.
Press the <NC START> key.
Machining starts. The program is reloaded continuously.
At the end of the program or in case of <RESET>, the program is automatically removed
from the control system.
Note
The program can only be executed. Program correction is not possible at the control.
