Siemens SINUMERIK 840C Operator's Guide

4 Machine 01.99
6FC5198-6AA60-0BP1 © Siemens AG 1999 All Rights Reserved
4-38 SINUMERIK 840C, OEM Version for Windows (BA)
Press the GENERATE BLOCK softkey to generate a block before the teach
block (N16 in the figure).
Fig. 4-15 Generate block
Please note that the function GENERATE BLOCK generates the block created
in the block structure. For the example in the figure, the following settings
would be required:
’
Block number
Next block number
Block number difference
Axes
Block structure/settings
selected
5
16
yes
Axis selection
X
Y
Z
A
ja
no
yes
yes
no
Fig. 4-16 Settings for block structure
Generate
block
MPF 4711 Workpiece SHAFT1 Insert 4
N10 X0 Y0 Z0 G0 L
F
N15 Y125 G1 F500 L
F
N16 X= -25600 Y= 68.300 L
F
N20 G0 Y0 L
F
Notes
