01.99 4 Machine
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
4-73
• The machine area has been selected.
• AUTOMATIC or TEACH IN mode has been selected.
• The program sequence is stopped. Notes regarding the programming error
are displayed in the alarm line.
Press the CORRECT PROGRAM softkey.
Fig. 4-33 Program correction display
The block with the breakpoint or error is highlighted (N15 in the figure). If an
error causes the program to be interrupted, the advance decoding is interrupted
before the block containing the error. You can edit the block with the error and
all the following blocks.
If the error is detected only during processing (e.g. error in tool radius
compensation), the defective block is not marked; it is possible to detect this
via the block number in the alarm.
Neither is the block marked, nor is the block number displayed in the alarm.
If necessary, complete the relevant program section with block numbers and
start the program again.
If a program is interrupted by a CANCEL alarm, execution of the program can
be continued from the breakpoint by pressing NC START after the program
error has been eliminated. When you press the CANCEL key you acknowledge
the error message.
If a program is interrupted by a RESET alarm, the program can only be started
after the RESET key is pressed. Execution begins from the start of the
program.
After a RESET interruption, you can use the block search function to calculate
the breakpoint and go to this point. This means the complete program does not
have to be processed (see the section "Block search").
Preconditions
Operating
sequence
Correct
program
MPF 4711 Workpiece SHAFT1 Insert 4
N10 G1 F5000 X-80 L
F
N15 G32 X-80 Y0 I80 J-60 L
F
N20 G0 X0 Y25 Z1 L
F
N25 G01 Z-200 F500 L
F
N5 G0 X0 Y0 Z0 L
F
Note
Problem, remedy
Note
