01.99 5 Parameters
© Siemens AG 1999 All Rights Reserved 6FC5198-6AA60-0BP1
SINUMERIK 840C, OEM Version for Windows (BA)
5-13
Note
From SW version 5, also zero offsets from a subprogram Lx under Ny can be
activated via G58 Lx Ky or G59 Lx Ky.
The number of the zero offsets which can be stored is limited only by the size
of the part program memory.
Z
ZMR
M
ZMV
XMV
XMR
WWR
+X
X
Fig. 5-8 Example: Drilling and milling machine
