Tool management

6.7 Start-up of code carrier

HMI Advanced (IM4)

266 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0

BItem

BItem<n>=<line>

<n> := consecutive number of code carrier data within block<i>, in ascending order from 1

without gaps

<line> := analog Item<n>

Conversion rule for code carrier data <n> within a block. If the code carrier data is assigned

a tool dialog data T<n>, the dialog data is assigned the first value of the code carrier data in

the block.

Example:

BItem1 1 BCD C1, T2 '

Convert subtype before/after cutting

edge

dialog data 1 and tool dialog data 2

(1st value of block is relevant for T2)

Block and End_Block

Block<n> <repetition rule>

<n> := Consecutive number of block, ascending from 1 without gaps

<repetition rule> := * Item<n> | CONTIGUOUS BItem1

This is followed by a block of data BItem<n> (up to to keyword End_Block<n>), which is

stored on the code carrier in accordance with the <repetition rule>.

Note

For Block<n> *Item<n>, Item<n> must be defined before Block<n>.

End_Block: End identifier for a data block defined with Block<n>

Example:

Block1 * Item6 ' Repeat Block1 corresponding to the

value of

Item6

Block1 CONTIGUOUS BItem1 '

Continue reading Block 1 until the

count variable

BItem1 stops returning a value

incremented by 1.

Write Block1 for the number of times

specified in the dialog variable

assigned to BItem1.

End_Block<n>
