Siemens SINUMERIK Commissioning Manual

Programming
2.3 Variables
Expanding the user interface
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
2-23
Parameter Description
cb0:
cb1:
The CHANGE block defined for this variable is processed when
the dialog is opened (default setting). Multiple attributes are
separated by commas.
The CHANGE block defined for this variable is then only
processed if the value of the variable changes.
Help display file: Name of the PDF-file
Default: Empty
6 Help display
The name of the Help display file appears in double quotation marks. The display
appears automatically (instead of the previous graphic) if the cursor is positioned on this
variable.
7 System or user variable An item of system or user data on the NC/PLC can be assigned to the variable. The
system or user variable appears in double quotation marks.
References: Parameter Manual, "List of System Variables" /PGA1/
8 Position of short text Position of short text (distance from left, distance from top, width)
The positions are entered in pixels and relate to the upper left-hand corner of the main
body of the dialog. The entries are separated by commas.
9 Position of input/output field Position of input/output field (distance from left, distance from top, width, height)
The positions are entered in pixels and relate to the upper left-hand corner of the main
body of the dialog. The entries are separated by commas. If this position changes, the
positions of the short text, graphic text and unit text also change.
Foreground color, background color: The colors are separated by a comma. Color
settings are only relevant to the input/output field; colors cannot be specified for the
other texts.
Range of values: 1...10
Default:
Foreground color: Black, background color: white
The default colors of the input/output field are determined by the Write mode:
10 Colors
wr0:
wr1:
wr2:
wr3:
wr4:
wr5:
Foreground and background color: Window background color
Text color: Black, background color for window
Text color: Black, background color: white
As wr0
As wr1
As wr2
11 Help
(HMI Advanced only)
Help file:
Index:
Help text:
Path to the PDF-file
Index in the Help text file to the Help text
Help text for display in the Help text file
