Configure hotkeys and PLC keys
4.5 List of selectable states
Expanding the user interface
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
4-25
State Function
90 – /user screen form (tailstock)
1 ShopTurn settings
Machine hand (with "Machine manual" option)
State Function
19 Main screen
50 Measure tool
51 Measure tool – length manual X/user screen form
52 Measure tool – length manual Z/user screen form
53 Measure tool – zoom*/user screen form
54 Measure tool – /user screen form
55 Measure tool – /user screen form
56 Measure tool – calibration probe*/user screen form
57 Measure tool – /user screen form
58 Measure tool – automatic Z *
59 Measure tool – automatic X *
1300 Straight
1400 Bore
1410 Drilling – centered
1420 Drilling – thread centered
1433 Drilling – centering*
1434 Drilling – drilling*
1435 Drilling – reaming*
1440 Drilling – deep-hole drilling*
1453 Drilling – tapping*
1454 Drilling – thread milling*
1500 Turning
1513 Turning – cutting 1
1514 Turning – cutting 2
1515 Turning – cutting 3
1523 Turning – groove 1
1524 Turning – groove 2
1525 Turning – groove 3
1533 Turning – undercut form E
1534 Turning – undercut form F
1535 Turning – undercut thread DIN
1536 Turning – undercut thread DIN
1543 Turning – thread, longitudinal
1544 Turning – thread, taper
1545 Turning – thread, facing
1550 Turning – cut-off
