Configure hotkeys and PLC keys
4.5 List of selectable states
Expanding the user interface
4-26 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
State Function
1600 Milling*
1613 Milling – rectangular pocket*
1614 Milling – circular pocket*
1623 Milling – rectangular spigot*
1624 Milling – circular spigot*
1633 Milling – longitudinal groove*
1634 Milling – circumferential groove*
1640 Milling – polyhedron*
1670 Milling – engraving*
1730 Simulation – 3-window view*
1740 Simulation – side view*
1750 Simulation – front view*
90 – /user screen form (tailstock)
1 ShopTurn settings
MDI
State Function
20 MDI
Machine Auto
State Function
200 Current block display
210 Program control
220 Block search
230 – /user screen form
242 Simultaneous recording – 3-window view*
243 Simultaneous recording – side view*
244 Simultaneous recording – front view*
250 Settings
Program Manager
State Function
300 NC directory
310 Parts programs*
320 Subprograms*
330 User directory 1 *
340 User directory 2 *
350 User directory 3 *
