Appendix
A.1 List of start softkeys
Expanding the user interface
A-2 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
ShopMill SCxxx Output dialog
SC826 Machine Auto operating area (large
dialog)
Horizontal SK 6
SC8261 Machine Auto operating area (medium
dialog)
Horizontal SK 6
SC8262 Machine Auto operating area (small
dialog)
Horizontal SK 6
SC8426 Program-Drilling operating area Vertical SK 6
SC8436 Program-Milling operating area Vertical SK 6
SC8454 Program-Miscellaneous operating
area
Vertical SK 4
SC8951 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 1
SC8952 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 2
SC8953 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 3
SC8954 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 4
SC8955 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 5
SC8956 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 6
SC8957 Program-Miscellaneous-Workpiece
Zero operating area
Vertical SK 7
SC8961 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 1
SC8962 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 2
SC8963 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 3
SC8964 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 4
SC8965 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 5
SC8966 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 6
SC8967 Program-Miscellaneous-Measure Tool
operating area
Vertical SK 7
SC857 Messages/Alarms operating area Horizontal SK 7
SC858 Messages/Alarms operating area Horizontal SK 8
SC867 Tools/Zero offsets operating area Horizontal SK 7
SC8492 Program-G-Code-Editor operating
area
Horizontal SK 2 (contour
cycles support) *
SC8493 Program-G-Code-Editor operating
area
Horizontal SK 3 (drilling
cycles support) *
SC8494 Program-G-Code-Editor operating
area
Horizontal SK 4 (milling
cycles support) *
