Siemens SINUMERIK Commissioning Manual

A Appendix
A.1 List of start softkeys
Expanding the user interface
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
A-3
ShopMill SCxxx Output dialog
SC8495 Program-G-Code-Editor operating
area
Horizontal SK 5 (turning
cycles support) *
SC8496 Program-G-Code-Editor operating
area
Horizontal SK 6*
SC8406 Program-G-Code-Editor operating
area (expanded area)
Horizontal SK 6 (measuring
cycles support)
SC8407 Program-G-Code-Editor operating
area (expanded area)
Horizontal SK 7 (measuring
cycles support)
* These are Siemens dialogs.
ShopTurn SCxxx Output dialog
SC818 Machine Manual operating area (large
dialog)
Horizontal SK 8
SC8181 Machine Manual operating area
(medium dialog)
Horizontal SK 8
SC8182 Machine Manual operating area (small
dialog)
Horizontal SK 8
SC8131 Machine Manual-Workpiece Zero
operating area
Vertical SK 1
SC8132 Machine Manual-Workpiece Zero
operating area
Vertical SK 2
SC8133 Machine Manual-Workpiece Zero
operating area
Vertical SK 3
SC8134 Machine Manual-Workpiece Zero
operating area
Vertical SK 4
SC8135 Machine Manual-Workpiece Zero
operating area
Vertical SK 5
SC8136 Machine Manual-Workpiece Zero
operating area
Vertical SK 6
SC8137 Machine Manual-Workpiece Zero
operating area
Vertical SK 7
SC8141 Machine Manual-Measure Tool
operating area
Vertical SK 1
SC8142 Machine Manual-Measure Tool
operating area
Vertical SK 2
SC8143 Machine Manual-Measure Tool
operating area
Vertical SK 3
SC8144 Machine Manual-Measure Tool
operating area
Vertical SK 4
SC8145 Machine Manual-Measure Tool
operating area
Vertical SK 5
SC8146 Machine Manual-Measure Tool
operating area
Vertical SK 6
SC8147 Machine Manual-Measure Tool
operating area
Vertical SK 7
SC826 Machine Auto operating area (large
dialog)
Horizontal SK 6
