Siemens SINUMERIK

Appendix
A.3 List of accessible system variables
Expanding the user interface
A-12 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Name Index Description
$MN_MAX_SUMCORR_
PERCUTTING_EDGE
Max. number of total offsets per cutting edge
$MN_MM_KIND_OF_SUMCORR Properties of total offsets in NCK
$MN_MM_NUM_CC_MAGAZINE_
PARAM
Number of parameters for one tool magazine
$MN_MM_NUM_CC_MAGLOC_
PARAM
Number of parameters for one tool magazine
location
$MN_MM_NUM_CC_MON_ PARAM Number of parameters of monitoring user data
of one tool edge
$MN_MM_NUM_GLOBAL_BASE_
FRAMES
Number of channel-dependent basic frames
$MN_MM_NUM_SUMCORR Total number of total offsets in NCK
$MN_MM_NUM_TOOL_ADAPTER Max. number of traversed tool adapter data
blocks
$MN_MM_TOOL_MANAGEMENT_
MASK
Settings NCK tool management
$P_UBFR[ x ,MI] x=FrameNo Mirroring of settable frame
$P_UBFR[x,RT] x=FrameNo Rotation of settable frame
$P_UBFR[x,SC] x=FrameNo Scaling factor of settable frame
$P_UBFR[x,SI] x=FrameNo Fine offset for frames
$P_UBFR[x,TR] x=FrameNo Translation of settable frame
$P_CHBFRMASK Active channel-specific basic frames
$P_EG_BC[a] EG block change criterion
$P_NCBFRMASK Active channel-independent basic frames
$P_OFFN Offset normal
$P_PFRAME[x,TR]
$P_ACTFRAME
$P_IFRAME
or
or
Compilation of active frame
$P_TOOL Number of active tool edge
$P_TOOLL[1] Active tool length 1
$P_TOOLL[2] Active tool length 2
$P_TOOLL[3] Active tool length 3
$P_TOOLND[x] x=ToolNo Number of cutting edges
$P_TOOLNO Number of active tool
$P_TOOLR Active tool radius
$P_UIFR[x,y,MI] x=FrameNo, y=Axis Mirroring of settable frame
$P_UIFR[x,y,RT] x=FrameNo, y=Axis Rotation of settable frame
$P_UIFR[x,y,SC] x=FrameNo, y=Axis Scaling factor of settable frame
$P_UIFR[x,y,SI] x=FrameNo, y=Axis Fine offset for frames
$P_UIFR[x,y,TR] x=FrameNo, y=Axis Translation of settable frame
$P_UIFRNUM Index of active set frame
$R[x] x=ParameterNo R parameters
$SC_PA_ACTIV_IMMED[x] x=Number protection zone Immediately active after referencing
$SC_PA_CENT_ABS[x,0] x=Number protection zone Abscissa of arc center of 1st contour element
