Name Index Description
$SC_PA_CENT_ABS[x,1] x=Number protection zone Abscissa of arc center of 2nd contour element
$SC_PA_CENT_ABS[x,2] x=Number protection zone Abscissa of arc center of 3rd contour element
$SC_PA_CENT_ABS[x,3] x=Number protection zone Abscissa of arc center of 4th contour element
$SC_PA_CENT_ABS[x,4] x=Number protection zone Abscissa of arc center of 5th contour element
$SC_PA_CENT_ABS[x,5] x=Number protection zone Abscissa of arc center of 6th contour element
$SC_PA_CENT_ABS[x,6] x = Number protection zone Abscissa of arc center of 7th contour element
$SC_PA_CENT_ABS[x,7] x=Number protection zone Abscissa of arc center of 8th contour element
$SC_PA_CENT_ABS[x,8] x=Number protection zone Abscissa of arc center of 9th contour element
$SC_PA_CENT_ABS[x,9] x=Number protection zone Abscissa of arc center of 10th contour element
$SC_PA_CENT_ORD[x,0] x=Number protection zone Ordinate of arc center of 1st contour element
$SC_PA_CENT_ORD[x,1] x=Number protection zone Ordinate of arc center of 2nd contour element
$SC_PA_CENT_ORD[x,2] x=Number protection zone Ordinate of arc center of 3rd contour element
$SC_PA_CENT_ORD [x,3] x=Number protection zone Ordinate of arc center of 4th contour element
$SC_PA_CENT_ORD[x,4] x=Number protection zone Ordinate of arc center of 5th contour element
$SC_PA_CENT_ORD[x,5] x=Number protection zone Ordinate of arc center of 6th contour element
$SC_PA_CENT_ORD[x,6] x=Number protection zone Ordinate of arc center of 7th contour element
$SC_PA_CENT_ORD[x,7] x=Number protection zone Ordinate of arc center of 8th contour element
$SC_PA_CENT_ORD[x,8] x=Number protection zone Ordinate of arc center of 9th contour element
$SC_PA_CENT_ORD[x,9] x=Number protection zone Ordinate of arc center of 10th contour element
$SC_PA_CONT_ABS[x,0] x=Number protection zone Abscissa of end point of 1st contour element
$SC_PA_CONT_ABS[x,1] x=Number protection zone Abscissa of end point of 2nd contour element
$SC_PA_CONT_ABS[x,2] x=Number protection zone Abscissa of end point of 3rd contour element
$SC_PA_CONT_ABS[x,3] x=Number protection zone Abscissa of end point of 4th contour element
$SC_PA_CONT_ABS[x,4] x=Number protection zone Abscissa of end point of 5th contour element
$SC_PA_CONT_ABS[x,5] x=Number protection zone Abscissa of end point of 6th contour element
$SC_PA_CONT_ABS[x,6] x=Number protection zone Abscissa of end point of 7th contour element
$SC_PA_CONT_ABS[x,7] x=Number protection zone Abscissa of end point of 8th contour element
$SC_PA_CENT_ABS[x,8] x=Number protection zone Abscissa of end point of 9th contour element
$SC_PA_CONT_ABS[x,9] x=Number protection zone Abscissa of end point of 10th contour element
$SC_PA_CONT_NUM[x] x=Number protection zone Number of valid contour elements
$SC_PA_CONT_ORD[x,0] x=Number protection zone Ordinate of end point of 1st contour element
$SC_PA_CONT_ORD[x,1] x=Number protection zone Ordinate of end point of 2nd contour element
$SC_PA_CONT_ORD[x,2] x=Number protection zone Ordinate of end point of 3rd contour element
$SC_PA_CONT_ORD[x,3] x=Number protection zone Ordinate of end point of 4th contour element
$SC_PA_CONT_ORD[x,4] x=Number protection zone Ordinate of end point of 5th contour element
$SC_PA_CONT_ORD[x,5] x=Number protection zone Ordinate of end point of 6th contour element
$SC_PA_CONT_ORD[x,6] x=Number protection zone Ordinate of end point of 7th contour element
$SC_PA_CONT_ORD[x,7] x=Number protection zone Ordinate of end point of 8th contour element
$SC_PA_CONT_ORD[x,8] x=Number protection zone Ordinate of end point of 9th contour element
$SC_PA_CONT_ORD[x,9] x=Number protection zone Ordinate of end point of 10th contour element
$SC_PA_CONT_TYP[x,0] x=Number protection zone Contour type of 1st contour element
$SC_PA_CONT_TYP[x,1] x=Number protection zone Contour type of 2nd contour element
