Siemens SINUMERIK

Appendix
A.3 List of accessible system variables
Expanding the user interface
A-14 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Name Index Description
$SC_PA_CONT_TYP[x,2] x=Number protection zone Contour type of 3rd contour element
$SC_PA_CONT_TYP[x,3] x=Number protection zone Contour type of 4th contour element
$SC_PA_CONT_TYP[x,4] x=Number protection zone Contour type of 5th contour element
$SC_PA_CONT_TYP[x,5] x=Number protection zone Contour type of 6th contour element
$SC_PA_CONT_TYP[x,6] x=Number protection zone Contour type of 7th contour element
$SC_PA_CONT_TYP[x,7] x=Number protection zone Contour type of 8th contour element
$SC_PA_CONT_TYP[x,8] x=Number protection zone Contour type of 9th contour element
$SC_PA_CONT_TYP[x,9] x=Number protection zone Contour type of 10th contour element
$SC_PA_LIM_3DIM[x] x=Number protection zone Limitation of protection zone, applicate
$SC_PA_MINUS_LIM[x] x=Number protection zone Lower limit of protection zone, applicate
$SC_PA_ORI[x] x=Number protection zone Plane assignment of protection zone
$SC_PA_PLUS_LIM[x] x=Number protection zone Upper limit of protection zone, applicate
$SC_PA_T_W[x] x=Number protection zone Workpiece or tool-related protection zone
$SN_PA_ACTIV_ IMMED[x] x=Number protection zone Immediately active after referencing
$SN_PA_CENT_ABS[x,0] x=Number protection zone Abscissa of arc center of 1st contour element
$SN_PA_CENT_ABS[x,1] x=Number protection zone Abscissa of arc center of 2nd contour element
$SN_PA_CENT_ABS [x,2] x=Number protection zone Abscissa of arc center of 3rd contour element
$SN_PA_CENT_ABS[x,3] x=Number protection zone Abscissa of arc center of 4th contour element
$SN_PA_CENT_ABS[x,4] x=Number protection zone Abscissa of arc center of 5th contour element
$SN_PA_CENT_ABS[x,5] x=Number protection zone Abscissa of arc center of 6th contour element
$SN_PA_CENT_ABS[x,6] x=Number protection zone Abscissa of arc center of 7th contour element
$SN_PA_CENT_ABS[x,7] x=Number protection zone Abscissa of arc center of 8th contour element
$SN_PA_CENT_ABS[x,8] x=Number protection zone Abscissa of arc center of 9th contour element
$SN_PA_CENT_ABS[x,9] x=Number protection zone Abscissa of arc center of 10th contour element
$SN_PA_CENT_ORD[x,0] x=Number protection zone Ordinate of arc center of 1st contour element
$SN_PA_CENT_ORD[x,1] x=Number protection zone Ordinate of arc center of 2nd contour element
$SN_PA_CENT_ORD [x,2] x=Number protection zone Ordinate of arc center of 3rd contour element
$SN_PA_CENT_ORD[x,3] x=Number protection zone Ordinate of arc center of 4th contour element
$SN_PA_CENT_ORD[x,4] x=Number protection zone Ordinate of arc center of 5th contour element
$SN_PA_CENT_ORD[x,5] x=Number protection zone Ordinate of arc center of 6th contour element
$SN_PA_CENT_ORD[x,6] x=Number protection zone Ordinate of arc center of 7th contour element
$SN_PA_CENT_ORD[x,7] x=Number protection zone Ordinate of arc center of 8th contour element
$SN_PA_CENT_ORD[x,8] x=Number protection zone Ordinate of arc center of 9th contour element
$SN_PA_CENT_ORD[x,9] x=Number protection zone Ordinate of arc center of 10th contour element
$SN_PA_CONT_ABS[x,0] x=Number protection zone Abscissa of end point of 1st contour element
$SN_PA_CONT_ABS[x,1] x=Number protection zone Abscissa of end point of 2nd contour element
$SN_PA_CONT_ABS[x,2] x=Number protection zone Abscissa of end point of 3rd contour element
$SN_PA_CONT_ABS [x,3] x=Number protection zone Abscissa of end point of 4th contour element
$SN_PA_CONT_ABS[x,4] x=Number protection zone Abscissa of end point of 5th contour element
$SN_PA_CONT_ABS[x,5] x=Number protection zone Abscissa of end point of 6th contour element
$SN_PA_CONT_ABS[x,6] x=Number protection zone Abscissa of end point of 7th contour element
$SN_PA_CONT_ABS[x,7] x=Number protection zone Abscissa of end point of 8th contour element
