Siemens SINUMERIK Commissioning Manual

A Appendix
A.3 List of accessible system variables
Expanding the user interface
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
A-15
Name Index Description
$SN_PA_CONT_ABS[x,8] x=Number protection zone Abscissa of end point of 9th contour element
$SN_PA_CONT_ABS[x,9] x=Number protection zone Abscissa of end point of 10th contour element
$SN_PA_CONT_NUM[x] x=Number protection zone Number of valid contour elements
$SN_PA_CONT_ORD[x,0] x=Number protection zone Ordinate of end point of 1st contour element
$SN_PA_CONT_ORD[x,1] x=Number protection zone Ordinate of end point of 2nd contour element
$SN_PA_CONT_ORD[x,2] x=Number protection zone Ordinate of end point of 3rd contour element
$SN_PA_CONT_ORD[x,3] x=Number protection zone Ordinate of end point of 4th contour element
$SN_PA_CONT_ORD[x,4] x=Number protection zone Ordinate of end point of 5th contour element
$SN_PA_CONT_ORD[x,5] x=Number protection zone Ordinate of end point of 6th contour element
$SN_PA_CONT_ORD[x,6] x=Number protection zone Ordinate of end point of 7th contour element
$SN_PA_CONT_ORD[x,7] x=Number protection zone Ordinate of end point of 8th contour element
$SN_PA_CONT_ORD[x,8] x=Number protection zone Ordinate of end point of 9th contour element
$SN_PA_CONT_ORD[x,9] x=Number protection zone Ordinate of end point of 10th contour element
$SN_PA_CONT_TYP[x,0] x=Number protection zone Contour type of 1st contour element
$SN_PA_CONT_TYP[x,1] x=Number protection zone Contour type of 2nd contour element
$SN_PA_CONT_TYP[x,2] x=Number protection zone Contour type of 3rd contour element
$SN_PA_CONT_TYP[x,3] x=Number protection zone Contour type of 4th contour element
$SN_PA_CONT_TYP[x,4] x=Number protection zone Contour type of 5th contour element
$SN_PA_CONT_TYP[x,5] x=Number protection zone Contour type of 6th contour element
$SN_PA_CONT_TYP[x,6] x=Number protection zone Contour type of 7th contour element
$SN_PA_CONT_TYP[x,7] x=Number protection zone Contour type of 8th contour element
$SN_PA_CONT_TYP[x,8] x=Number protection zone Contour type of 9th contour element
$SN_PA_CONT_TYP[x,9] x=Number protection zone Contour type of 10th contour element
$SN_PA_LIM_3DIM[x] x=Number protection zone Limitation of protection zone, applicate
$SN_PA_MINUS_LIM[x] x=Number protection zone Lower limit of protection zone, applicate
$SN_PA_ORI[x] x=Number protection zone Plane assignment of protection zone
$SN_PA_PLUS_LIM[x] x=Number protection zone Upper limit of protection zone, applicate
$SN_PA_T_W[x] x=Number protection zone Workpiece or tool-related protection zone
$TC_ADPT ... Adapter data
$TC_ADPTx
$TC_ADPTT
x=1 to 3 Number of parameters per adapter
$TC_DPCE Transformed edge correction value
$TC_DPCx[y,z] x=ParamNo
y=ToolNo, z=EdgeNo
User-defined tool edge parameter
$TC_DPx[y,z] x=ParamNo
y=ToolNo, z=EdgeNo
Edge correction value
$TC_DPx[y,z] x=ParamNo
y=ToolNo, z=EdgeNo
Transformed edge correction value
$TC_ECP ... Transformed location-dependent setup
correction
$TC_MAMP3 Wear compound strategy
$TC_MAP1 Type of magazine
$TC_MAP2 Identifier of the magazine
