Siemens SINUMERIK Commissioning Manual

Commissioning a system
1.2 User administration
PCU-Basesoftware (IM8)
Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
11
"Startup (1)" tab
Figure 1-2 Global Settings: Startup (1) tab
Table 1- 1 The default is marked in "bold".
Startup (1) tab Option Effect
Background
Bitmaps folder: F:\hmi_adv\ib\data\10700\0 Directory with boot screens
Default bitmap folder: F:\hmi_adv\ib\data\default Directory containing default boot screens
Installing
Enable: "yes" Authorization is in place to install user
software during booting.
"no" No installation authorization
Logon dialog: "no" Display "Service Logon" dialog.
"yes" Do not display "Service Logon" dialog.
Veto Dialog: "no" For pending installation during the boot up:
No prompting, the installation begins
immediately.
"yes" For pending installation during the boot up:
Prompt asking whether to install.
