Commissioning a system
1.2 User administration
PCU-Basesoftware (IM8)
12 Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
Startup (1) tab Option Effect
Authentication: "manual" Authentication of an HMI+Service user in
the "Service Logon" dialog is undertaken
manually.
"EKS" Authentication of an HMI+Service user in
the "Service Logon" dialog involves EKS.
The "Service Logon" dialog appears if
authentication by EKS has failed in the
background.
"manual+EKS" Authentication of an HMI+Service user in
the "Service Logon" dialog either involves
EKS or is performed manually.
"Startup (2)" tab
Figure 1-3 "Startup (2)" tab
Table 1- 2 The default is marked in "bold".
Startup (2) tab Option Effect
Desktop Logon
Start dialog: "yes" Display "Desktop Access" dialog.
"no" Do not display "Desktop Access" dialog.
Logon Dialog: "yes" Display "Desktop Logon" dialog.
"no" Do not display "Desktop Logon" dialog.
Default password map: "no" The password must be entered exactly as
specified.
