Commissioning a system
1.4 BIOS settings
PCU-Basesoftware (IM8)
28 Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
BIOS setup: Defaults
The following system parameters are saved on delivery:
Menu: Main
System parameters Defaults Custom entries
System Time hh:mm:ss
System Date MM/DD/YYYY
IDE Channel 0 Master None
IDE Channel 0 Slave None
SATA Port 0 40008 MB
SATA Port 1 None
SATA Port 2 None
SATA Port 3 None
Memory Cache Write Back
Boot options
Quick boot mode Enabled
SETUP prompt Enabled
POST errors All, but not keyboard
Summary screen Enabled
Diagnostic screen Enabled
Post Code/Status LPC Bus
Keyboard features
Numlock ON
Key click Disabled
Keyboard auto-repeat rate 30 / sec
Keyboard auto-repeat delay ½ sec
Hardware Options
PCI MPI/DP Enabled
Onboard Ethernet 1 Enabled
On-board Ethernet 1 Address 08 00 06 90 xx xx
On-board Ethernet 1 Remote Boot Enabled
Onboard Ethernet 2 Enabled
On-board Ethernet 2 Address 08 00 06 90 xx xx
On-board Ethernet 2 Remote Boot Disabled
SafeCard functions Enabled
Fan control Enabled
CRT/LCD selection Simultan. Auto
