Commissioning a system
1.4 BIOS settings
PCU-Basesoftware (IM8)
Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
29
Menu: Advanced
System parameters Defaults Custom entries
Installed O/S Other
Reset configuration data No
Legacy USB support Disabled
USB controller restart Enabled
I/O Device Configuration
Internal COM 1 Enabled
Base I/O address 3F8
Interrupt IRQ 4
PCI Configuration
PCI device slot 1
Option ROM scan Enabled
Enable master Enabled
Latency timer Default
PCI device slot 2
Option ROM scan Enabled
Enable master Enabled
Latency timer Default
SATA/PATA Configuration
PATA Controller: Enabled
SATA Controller mode Enhanced
AHCI Configuration Disabled
RAID support Disabled
Menu: Security
System parameters Defaults Custom entries
Supervisor password is Disabled
User password is Disabled
Set user password Enter
Set supervisor password Enter
Password on boot Disabled
Fixed disk boot sector Standard
