Commissioning a system
1.4 BIOS settings
PCU-Basesoftware (IM8)
30 Commissioning Manual, 03/2009, 6FC5397-1DP10-4BA0
Menu: Boot
System parameters Defaults Custom entries
Boot priority order:
1: SATA0: Fujitsu MHT2040BHTBD
2: PCI BEV: VIA BootAgent
3:
4:
5:
6:
7:
8:
Excluded from boot order:
Menu: Version
System parameters Defaults
SIMATIC PC SINUMERIK PCU50.3
BIOS version V05.01.06
BIOS number A5E00370214-ES005
MPI/DP firmware V01
CPU type Celeron ® M processor 1.50GHz
CPU ID 06D8
Code revision 0020
Menu: Exit
Save Changes & Exit All changes are saved; a system restart is carried out with the
new parameters.
Changing BIOS settings
Once additional components have been installed or attached, it may be the case that the
system has to be informed of this via the BIOS setup:
1. Ramp up the device.
2. When the prompt to activate the BIOS setup appears, press the <F2> key (corresponds
to horizontal softkey 2 on the OP).
3. The BIOS setup menu appears. In the menu, use the cursor keys to navigate to the
desired selection box.
4. Change the setting using the <+> key (press <SHIFT> and <X> at the same time) or the
↔ key on in the numeric keypad.
5. Using the left-right cursor keys, you can reach other setup menus.
