Configuring the HMI system
2.3 Connecting network drives
HMI Advanced (IM4)
70 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
Connection type / connection
The following connections can be selected.
No drive: No additional fields are displayed:
Local USB: Designation of the local USB interface:
- Front (0.2 or 1:0.2 or FRONT)
- X203 (1 or 1:1 or X203)
- X204 (2 or 1:2 or X204)
Partition:
(for local and global USB)
e.g. 1
Global USB: Designation of the global USB interface:
- Front (0.2 or 1:0.2 or FRONT)
- X203 (1 or 1:1 or X203)
- X204 (2 or 1:2 or X204)
Device: (only for global USB) e.g. TCU1
NW Windows: Designation of the network drive (under Windows). The path
must begin with \\.
User name:
(only for NW Windows)
The user name can be entered in the user interface, e.g.
Mustermann.
Password:
(only for NW Windows)
The password is displayed on the user interface with a *. It is
encoded and entered in the logdrive.ini file.
Local drive: Drive letter, e.g. D:
Access authorizations
The access authorizations to the connections can be assigned from level 0 to 7. If no entry is
made, the default setting is applied (7 = Access for all).
Only one access level can be specified for all the operating areas:
● Machine
● Program
● Services
Softkey labels
Two lines with a maximum of 10 characters are available for the labeling text of a softkey.
\n,%n or two blanks can be used to separate lines.
For labeling the softkeys, the alarm texts 89901- 89906 are evaluated in order to store
language-dependent softkey texts if no other labeling is defined.
Data transfer to and from the TCU
The USB interface of the TCU that is currently active is always the one accessed, i.e. has
the operator focus. If the active TCU changes during a data transfer, the data transfer
remains active in the background.
