Parameterizing/addressing
9.3 Overview of parameters
SIPART PS2 with and without HART
152 Operating Instructions, 10/2013, A5E00074631-11
Parameter
Function
Parameter values
Unit
41.YCUP
Upper value for tight closing
0.0 ... 99.5 ... 100 %
%
42.BIN1 2)
Function of BE1
Normally open
Normally closed
None
OFF
Message only
on
-on
Block configuration
bloc1
Block configuration and manual
bloc2
Move valve to position YE
uP
-uP
Move valve to position YA
doWn
-doWn
Block movement
StoP
-StoP
Partial-Stroke-Test
PST
-PST
43.BIN2 2)
Function of BE2
Normally open
Normally closed
None
OFF
Message only
on
-on
Move valve to position YE
uP
-uP
Move valve to position YA
doWn
-doWn
Block movement
StoP
-StoP
Partial-Stroke-Test PST -PST
44.AFCT 3)
Alarm function
Normal
Inverted
None
OFF
A1 = Min, A2 = Max
A1 = Min, A2 = Min
A1 = Max, A2 = Max
45.A1
Trigger threshold, alarm 1
0.0 ... 10.0 ... 100 %
%
46.A2
Trigger threshold, alarm 2
0.0 ... 90.0 ... 100 %
%
47. FCT 3)
Function for fault message output
Normal
Inverted
Fault
Fault + not automatic
4)
Fault + not automatic + BE
4)
48. TIM Monitoring time for setting of fault message
"regulation deviation"
Auto
/ 0 ... 100 s
49. LIM Response threshold for fault message
"regulation deviation"
Auto
/ 0 ... 100 %
