Alarm, error, and system messages
10.1 Output of system messages in the display
SIPART PS2 with and without HART
204 Operating Instructions, 10/2013, A5E00074631-11
RUN1 /
ERROR
X Error in "RUN1", no movement e.g. due to
the lack of compressed air
• Provide adequate compressed air
• Open the restrictor(s)
• Restart the initialization process
d___U X Bar graph display of the zero point; zero
point is beyond the tolerance range
• Set between "P 4.0" and "P .9" ( >0< )
using a friction clutch
• Continue with the "+" or "-" button
Friction clutch was moved; "P 50.0" not
displayed when the lever is horizontal
• In case of linear actuators, use the "+"
and "-" buttons to bring the lever
perpendicular to the spindle
• Press the operating mode button slightly
to acknowledge (the initialization process
is continued)
MIDDL X
UP > X "UP" tolerance range was exceeded or the
inactive zone of the potentiometer was
covered
• Increase the effective lever length of the
linear actuators or switch the
transmission ratio selector to 90°
• Press the operating mode button slightly
to acknowledge
• Restart the initialization process
90_95 X Possible only in case of part-turn actuators:
actuator travel is not in the range between 90
and 95%
• Use the "+" and "-" buttons to move it in
the range between 90 and 95%
• Press the operating mode button slightly
to acknowledge
U-d> X "Up-Down" measuring span was undershot
• Decrease the effective lever length of the
linear actuators or switch the
transmission ratio selector to 33°
• Press the operating mode button slightly
to acknowledge
• Restart the initialization process
Display of the "Up" travel time
• Wait, or
• To change the travel time, interrupt the
initialization process with the "-" button,
or
• Activate the leakage test with the "+"
button
D->U X
Display of the "Down" travel time
• Wait, or
• To change the travel time, interrupt the
initialization process with the "-" button,
or
• Activate the leakage test with the "+"
button
U->d X
