Description
3.2 Structure
SIPART PS2 with and without HART
20 Operating Instructions, 10/2013, A5E00074631-11
①
Single-acting positioner in flameproof aluminum enclosure
②
Pressure gauge block, single-acting
③
Yoke / actuator yoke
④
Actuator
Figure 3-3 Positioner in flameproof aluminum enclosure attached to linear actuator
①
Part-turn actuator
②
Double-acting positioner in flameproof aluminum enclosure
③
Pressure gauge block, double-acting
Figure 3-4 Positioner in flameproof aluminum enclosure attached to part-turn actuator
