SWT 3000 Equipment Manual ALRS and ALR Module
© SIEMENS AG 2008 Edition p3_3_2x 08/09 Page - 9
ALR jumper settings
The function of the ALR jumpers is shown in the table below.
Table 6: Setting options for the ALR module
Jumpers
X2 X3 X4 X5 – X13 X14 – X17
Binary Input 1
250V X2 – 7 / 8
*)
open --- --- X14 – X15
*)
110V X2 – 1 / 2 open --- --- X14 – X15
48V /
60V
X2 – 3 / 4 open --- --- X14 – X15
24V X2 – 5 / 6 open --- --- X14 – X15
Input behaviour
fast
slow
X18 / 3 – 4
X18 / 1 - 2
IRIG-B
24V open X3 – 1 / 2 --- --- X16 – X17
12V open X3 – 3 / 4 --- --- X16 – X17
5V open X3 – 5 / 6 --- --- X16 – X17
Binary Input 2
250V --- --- X4 – 7 / 8
*)
--- ---
110V --- --- X4 – 1 / 2 --- ---
48V /
60V
--- --- X4 – 3 / 4 --- ---
24V --- --- X4 – 5 / 6 --- ---
Input behaviour
fast
slow
X19 / 3 – 4
X19 / 1 - 2
Alarm Output 1 Relay K1
NC --- --- --- X5 – X6
*)
---
NO --- --- --- X6 – X7 ---
Alarm Output 2 Relay K2
NC --- --- --- X8 – X9
*)
---
NO --- --- --- X9 – X10 ---
Alarm Output 3 Relay K3
NC --- --- --- X11 – X12
*)
---
NO --- --- --- X12 – X13 ---
NC Break contact
NO Make contact
*) Default setting
