Displays and operating elements
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 11 of 109
2.2.2 Drive status
In factory setting, the , , ,  LEDs inform about the drive’s status.
The function of the drive status LEDs can be configured.
2.2.2.1 Status LED 5
LED statuses valid with factory setting.
LED state
Description
Green
Operating voltage applied to control, no fault
Red, flashing
Operating voltage applied to control, active fault
Red/green,
flashing
Operating voltage applied to control, switch lock active
Off
Operating voltage of control missing
2.2.2.2 Status LEDs 6, 7
LED statuses valid with factory setting.
LED state
Description
Off
No function
2.2.2.3 Status LED 8
If the actual value is unequal 0 after switching on the module and if it is
outside the programmed positioning window, then the LED status is “red” or
“red, flashing” due to volatile storage of the setpoint. The setpoint is
initialized with the value 0 after switching on.
LED statuses valid with factory setting.
LED state
Description
Green
Actuator is within the programmed positioning window.
Operating voltage of the output stage is applied.
Green,
flashing
Actuator is within the programmed positioning window.
Operating voltage of final stage missing
Red
Actuator is outside the programmed positioning window.
Operating voltage of the output stage is applied.
Red, flashing
Actuator is outside the programmed positioning window.
Operating voltage of final stage missing
Off
Operating voltage of control missing.
