8.2.1.2.3 Control word: Speed mode
Bit
Description
Bit 0
OFF1 (enable )
0 = OFF1 active
Current travel job is canceled.
The actuator is enabled.
1 = OFF1 inactive
Bit 1
OFF2 (max. delay)
0 = OFF2 active
Current travel job is canceled.
The actuator is decelerated with max. delay, the actuator
continues to be controlled.
1 = OFF2 inactive
Bit 2
OFF3 (progr. delay)
0 = OFF3 active
Current travel job is canceled.
The actuator is decelerated with prog. delay, the actuator
continues to be controlled.
1 = OFF3 inactive
Bit 3
Reserved, always 0
Bit 4
Start travel job
Positive slope starts a travel job
Bit 5
Acknowledge error
Positive slope acknowledges an error
Afterwards, the actuator changes to the switch-lock state.
Bit 6 … 15
Reserved, always 0
Table 3: Control word of speed mode
