EtherCAT®
AG25, AG26
Date: 09
.0
7.2018
Art. No. 88094
Mod. status
225
/
18
Page
31
of 109
8.2.1
Parameter description o
f manufactu
rer-specific objec
ts
8.2.1.1
Digital Outputs Contr
ol
Object
2001h
Description
Digital output control b
yte
Access
rw (component of proc
ess data)
Data type
UNSIGNED8
Default
No
EEPROM
No
Value range
UNSIGNED8
Bit
Description
0
Digital output 1:
1 … 7
Reserved, alwa
ys 0
8.2.1.2
Control Word
Object
2002h
Description
Control word
Access
rw (component of proc
ess data)
Data type
UNSIGNED16
Default
No
EEPROM
No
Value range
UNSIGNED16
30
32
Table of Contents
Default Chapter
2
Table of Contents
2
1 General Information
9
Documentation
9
2 Displays and Operating Elements
9
Displays
9
Ethernet Module Statuses
10
Error Led 1
10
Link/Activity LED 2, 3
10
Run Led 4
10
Drive Status
11
Status LED 5
11
Status LED 8
11
Status Leds 6, 7
11
Operating Elements
12
Operating Keys
12
DIP Switch
13
3 Digital Inputs and Outputs
13
Examples of Digital Input Configurations
14
Example of Digital Output Configuration
15
4 Functional Description
16
Control of the Drive
16
Operating Modes
16
Positioning Mode
16
4.1.1.1.1 Loop Positioning
17
Inching Mode
18
Inching Mode 1
18
Inching Mode 2
19
Rotational Speed Mode
19
Position Control Mode
20
4.1.1.4.1 Examples of Configuration of the Digital Inputs for the PCM
21
Current Limiting
22
Limit Switch
23
Arrangement of the Limit Switches
23
Example of Limit Switch Configuration
23
5 Calibration
24
6 External Gear
24
7 Warnings / Errors
25
Warnings
25
Errors
25
Error Codes
26
8 Ethercat
27
Description
27
Cyclic Data Exchange
27
Acyclic Data Exchange
27
Operating Modes and Synchronization
27
Emergency Messages
27
Object Directory (Canopen over Ethercat®)
28
Parameter Description of Manufacturer-Specific Objects
31
Control Word
31
Digital Outputs Control
31
Control Word Positioning Mode (Master Slave)
32
8.2.1.2.2 Flow Chart: Operating Mode: Positioning Mode
33
8.2.1.2.3 Control Word: Speed Mode
34
8.2.1.2.4 Flow Chart: Speed Mode
35
Digital Inputs State
36
Status Word
36
Target Value
36
Status Word: Positioning Mode (Slave Master)
37
8.2.1.5.2 Status Word: Speed Mode
38
Actual Value
39
LED Functionality
39
Digital Output 1 Functionality
41
Service Interface Baud Rate
41
Digital Output Functionalities State
42
Digital Outputs Polarity
42
Digital Input 1 Functionality
43
Digital Input 2 Functionality
43
Digital Input 3 Functionality
44
Digital Input 4 Functionality
44
Digital Input Functionalities State
45
Controller Parameter I
46
Controller Parameter P
46
Digital Inputs Polarity
46
A-Pos
47
Controller Parameter D
47
V-Pos
47
A-Inch
48
A-Rot
48
D-Pos
48
Gear Ratio Numerator
49
Pos Window
49
V-Inch
49
Gear Ratio Denominator
50
Spindle Pitch
50
Calibration Value
50
Software Limit 1
51
Software Limit 2
51
Delta Inch
52
Sense of Rotation
52
Pos Type
53
Operating Mode
53
Inching 2 Stop Mode
54
Inpos Mode
54
Loop Length
55
Contouring Error Limit
55
Current Limiting
56
Inching 2 Offset
56
Inching 2 Acceleration Type
57
Offset Value
57
PCM Position 1
58
PCM Position 2
58
PCM Position 3
58
PCM Position 4
59
PCM Position 5
59
PCM Position 6
59
PCM Position 7
60
PCM Acceleration 1
60
PCM Acceleration 2
60
PCM Acceleration 3
61
PCM Acceleration 4
61
PCM Acceleration 5
61
PCM Acceleration 6
62
PCM Acceleration 7
62
PCM Velocity 1
62
PCM Velocity 2
63
PCM Velocity 3
63
PCM Velocity 4
63
PCM Velocity 5
64
PCM Velocity 6
64
PCM Velocity 7
64
PCM Deceleration 1
65
PCM Deceleration 2
65
PCM Deceleration 3
66
PCM Deceleration 4
66
PCM Deceleration 5
67
PCM Deceleration 6
67
PCM Deceleration 7
68
Output Stage Temperature
68
Voltage of Control
68
Voltage of Output Stage
69
Voltage of Battery
69
Motor Current
69
Actual Position
69
Actual Rotational Speed
70
Serial Number
70
Production Date
70
SW Motor Controller
70
Gear Reduction
71
System Status Word
71
Encoder Resolution
73
Device ID
73
Number of Errors
74
Error Number 1
74
Error Number 2
74
Error Number 3
74
Error Number 4
75
Error Number 5
75
Error Number 6
75
Error Number 7
75
Error Number 8
76
Error Number 9
76
Error Number 10
76
Configuration
77
S-Command
77
Standard Objects Parameter Description
78
Device Type
78
Error Register
78
Pre-Defined Error Field
78
Manufacturer Device Name
79
Manufacturer Hardware Version
79
Manufacturer Software Version
79
Restore Default Parameters
79
Identity Object
80
Receive PDO Mapping
81
Transmit PDO Mapping
82
Sync Manager Communication Type
82
Sync Manager Rx PDO Assign
83
Sync Manager Tx PDO Assign
84
SM Output Parameters
84
SM Input Parameters
86
