Siko AG25 - PCM Velocity 2; PCM Velocity 3; PCM Velocity 4

EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 63 of 109
8.2.1.61 PCM Velocity 2
Object
2963h
Description
Positioning mode via digital inputs: Velocity 2
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
8.2.1.62 PCM Velocity 3
Object
2964h
Description
Positioning mode via digital inputs: Velocity 3
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
8.2.1.63 PCM Velocity 4
Object
2965h
Description
Positioning mode via digital inputs: Velocity 4
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
