Siko AG25 - PCM Velocity 5; PCM Velocity 6; PCM Velocity 7

EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 64 of 109
8.2.1.64 PCM Velocity 5
Object
2966h
Description
Positioning mode via digital inputs: Velocity 5
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
8.2.1.65 PCM Velocity 6
Object
2967h
Description
Positioning mode via digital inputs: Velocity 6
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
8.2.1.66 PCM Velocity 7
Object
2968h
Description
Positioning mode via digital inputs: Velocity 7
Access
rw
Data type
INTEGER16
Default
10
EEPROM
Yes
Value range
Transmission 66:1  max. 75 rpm
Transmission 98:1  max. 50 rpm
Transmission 188:1  max. 30 rpm
Transmission 368:1  max. 15 rpm
