Siko AG25 - PCM Position 1; PCM Position 2; PCM Position 3

EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 58 of 109
8.2.1.46 PCM Position 1
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2922h
Description
Positioning mode via digital inputs: Position 1
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
8.2.1.47 PCM Position 2
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2923h
Description
Positioning mode via digital inputs: Position 2
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
8.2.1.48 PCM Position 3
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2924h
Description
Positioning mode via digital inputs: Position 3
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
