Siko AG25 User Manual

EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 44 of 109
8.2.1.14 Digital Input 3 Functionality
This parameter determines the functionality of digital input 3.
With a value greater than 0 set, a function is assigned to the digital input.
The functional state can be read from the Digital Input Functionalities State register.
Object
2403h
Description
Digital input 3 functionality
Access
rw
Data type
UNSIGNED8
Default
0
EEPROM
Yes
Value range
0 … 11
Description, see Table 7: Configuration of digital inputs.
8.2.1.15 Digital Input 4 Functionality
This parameter determines the functionality of digital input 4.
With a value greater than 0 set, a function is assigned to the digital input.
The functional state can be read from the Digital Input Functionalities State register.
Object
2404h
Description
Digital input 4 functionality
Access
rw
Data type
UNSIGNED8
Default
0
EEPROM
Yes
Value range
0 … 11
Description, see Table 7: Configuration of digital inputs.
