Siko AG25 - PCM Position 4; PCM Position 5; PCM Position 6

EtherCAT®
AG25, AG26 Date: 09.07.2018 Art. No. 88094 Mod. status 225/18 Page 59 of 109
8.2.1.49 PCM Position 4
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2925h
Description
Positioning mode via digital inputs: Position 4
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
8.2.1.50 PCM Position 5
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2926h
Description
Positioning mode via digital inputs: Position 5
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
8.2.1.51 PCM Position 6
Spindle pitch = 0: Values refer to steps
Spindle pitch > 0 values refer to travel distance in 1/100 mm
Object
2927h
Description
Positioning mode via digital inputs: Position 6
Access
rw
Data type
INTEGER32
Default
0
EEPROM
Yes
Value range
INTEGER32
